6-28483-01-0-1 | SECA-40/92/8/24/1020/vIS/2285/730/760
Part No.6-28483-01-0-1
EAN 4015596782663
Area of application
Door technology
Area of application (specified)
Locks
Application system
Automate
Product type
Multi-point lock
Description of finish
ferGUard*silver
Gross weight
2,342 G
Packing unit
5 EA
Minimum ordering unit
1 EA
1 Version found
6-28483-01-0-8 | Multi-point lock | SECA-40/92/8/24/1020/vIS/2285/730/760
Part No.6-28483-01-0-8
EAN4015596844057
No content available
Attributes
Backset
40 mm
Faceplate dimension (in mm)
24 x 2,5
Hole distance
92 mm
Locking type (material short text)
sf2
Interior square of follower
8 mm
Top locking position 1 (A1)
730 mm
Faceplate length
2.285 mm
Type of faceplate
Flachstulp
Locking system
self-locking
A-opener
optional
Marking notch
1.020 mm
Cylinder hole-type
Profile cylinder
Faceplate end
Square
Locking type
From marking notch upwards and downwards respectively 1 Automatic latchbolt.
Bottom locking position 1 (B1)
760 mm
