6-31542-17-0-1 | SEC-MR2-35/92/8/24x6/1020/vIS/2285/730
Part No.6-31542-17-0-1
EAN 4015596812957
Area of application
Door technology
Area of application (specified)
Locks
Application system
SECURY V
Product type
Multi-point lock
Description of finish
ferGUard*silver
Gross weight
2.474 KG
Packing unit
2 EA
Minimum ordering unit
1 EA
1 Version found
6-31542-17-0-8 | Multi-point lock | SEC-MR2-35/92/8/24x6/1020/vIS/2285/730
Part No.6-31542-17-0-8
EAN4015596837950
No content available
Attributes
Backset
35 mm
Faceplate dimension (in mm)
24 x 6 x 6 x 2,5
Hole distance
92 mm
Locking type (material short text)
MR2
Interior square of follower
8 mm
Top locking position 1 (A1)
730 mm
Faceplate length
2.285 mm
Type of faceplate
U-Stulp
Locking system
manually locking
Marking notch
1.020 mm
Cylinder hole-type
Profile cylinder
Faceplate end
Square
Locking type
From marking notch upwards and downwards respectively 1 MR bolts
Bottom locking position 1 (B1)
760 mm
