6-32258-20-0-1 | SecE-R4 35/92/8/16 950/1765 Engl
Part No.6-32258-20-0-1
EAN 4015596932556
Area of application
Door technology
Area of application (specified)
Locks
Application system
EUROPE
Product type
Multi-point lock
Description of finish
ferGUard*silver
Gross weight
1.306 KG
Packing unit
240 EA
Minimum ordering unit
240 EA
No content available
Attributes
Backset
35 mm
Faceplate dimension (in mm)
16 x 2,5
Hole distance
92 mm
Locking type (material short text)
SZ-R4
Interior square of follower
8 mm
Top locking position 1 (A1)
267,5 mm
Top locking position 2 (A2)
737,5 mm
Faceplate length
1.765 mm
Type of faceplate
Flachstulp
Locking system
manually locking
Marking notch
950 mm
Mechanically coupled
Extendable at bottom (crop)
Cylinder hole-type
Profile cylinder
Faceplate end
Square
Locking type
From marking notch upwards and downwards respectively 2 roller-cams.
Bottom locking position 1 (B1)
402,5 mm
Bottom locking position 2 (B2)
872,5 mm
